AudioCodes Mediant 500L MSBR User Manual

User's Manual 284 Document #: LTRT-10466
Mediant 500L MSBR
Parameter Description
Interface Name
CLI: interface-name
[SIPInterface_InterfaceName]
Defines an arbitrary name to easily identify the SIP Interface.
The valid value is a string of up to 21 characters.
Network Interface
CLI: network-interface
[SIPInterface_NetworkInterface]
Assigns a Control-type IP network interface to the SIP
Interface. This string value must be identical (case-sensitive)
to that configured in the 'Interface Name' field of the Interface
table (see ''Configuring IP Network Interfaces'' on page 138).
By default, no value is defined.
Note: To create a SIP interface on the WAN interface,
configure this parameter with the string value, "WAN". This
WAN interface is selected in the Interface table (or use the
WANInterfaceName parameter), which is the WAN interface
address as defined in WAN Access Settings. If VLANs are
defined for the WAN interface and one of the VLANs is
selected as the VoIP WAN interface, then the defined SIP
Interface uses this interface.
Application Type
CLI: application-type
[SIPInterface_ApplicationType]
Defines the application type associated with the SIP
Interface.
 [0] GW/IP2IP (default) = Gateway / IP-to-IP application.
 [1] SAS = Stand-Alone Survivability (SAS) application.
 [2] SBC = SBC application.
UDP Port
CLI: udp-port
[SIPInterface_UDPPort]
Defines the listening and source UDP port.
The valid range is 1 to 65534. The default is 5060.
Notes:
 This port must be outside of the RTP port range.
 The base UDP port number (BaseUDPPort parameter)
for RTP traffic must be greater than the highest UDP port
configured for a SIP Interface. For example, if your
highest configured UDP port for a SIP Interface is 6060,
you must configure the BaseUDPPort parameter to any
value greater than 6060. For more information on base
UDP port, see Configuring RTP Base UDP Port on page
199.
 Each SIP Interface must have a unique signaling port
(i.e., no two SIP Interfaces can share the same port - no
port overlapping).
TCP Port
CLI: tcp-port
[SIPInterface_TCPPort]
Defines the listening TCP port.
The valid range is 1 to 65534. The default is 5060.
Notes:
 This port must be outside of the RTP port range.
 Each SIP Interface must have a unique signaling port
(i.e., no two SIP Interfaces can share the same port - no
port overlapping).
TLS Port
CLI: tls-port
[SIPInterface_TLSPort]
Defines the listening TLS port.
The valid range is 1 to 65534. The default is 5061.
Notes:
 This port must be outside of the RTP port range.
 Each SIP Interface must have a unique signaling port
(i.e., no two SIP Interfaces can share the same port - no
port overlapping).
