AudioCodes Mediant 500L MSBR User Manual

User's Manual 798 Document #: LTRT-10466
Mediant 500L MSBR
67.2.2 Routing Parameters
The IP network routing parameters are described in the table below.
Table 67-11: IP Network Routing Parameters
Parameter Description
Static Route Table
Web/EMS: Static Route
Table
CLI: configure voip > static
[StaticRouteTable]
Defines up to 30 static VoIP IP routes for the device.
The format of the ini file table parameter is as follows:
[ StaticRouteTable ]
FORMAT StaticRouteTable_Index = StaticRouteTable_DeviceName,
StaticRouteTable_Destination, StaticRouteTable_PrefixLength,
StaticRouteTable_Gateway, StaticRouteTable_Description;
[ \StaticRouteTable ]
For a description of this parameter, see ''Configuring Static IP Routes''
on page 147.
67.2.3 Quality of Service Parameters
The Quality of Service (QoS) parameters are described in the table below.
Table 67-12: QoS Parameters
Parameter Description
Layer-2 Class Of Service (CoS) Parameters (VLAN Tag Priority Field)
Web: DiffServ Table
EMS: QoS Settings – DSCP to QoS
Mapping
CLI: configure voip > vlan-mapping
[DiffServToVlanPriority]
This table parameter configures DiffServ-to-VLAN Priority
mapping. For each packet sent to the LAN, the VLAN
Priority of the packet is set according to the DiffServ
value in the IP header of the packet.
The format of this ini file is as follows:
[ DiffServToVlanPriority ]
FORMAT DiffServToVlanPriority_Index =
DiffServToVlanPriority_DiffServ,
DiffServToVlanPriority_VlanPriority;
[ \DiffServToVlanPriority ]
For example:
DiffServToVlanPriority 0 = 46, 6;
DiffServToVlanPriority 1 = 40, 6;
DiffServToVlanPriority 2 = 26, 4;
DiffServToVlanPriority 3 = 10, 2;
For a description of this table, see Configuring Quality of
Service on page 150.
Note: For this parameter to take effect, a device reset is
required.
Layer-3 Class of Service (TOS/DiffServ) Parameters
Web: Media Premium QoS
EMS: Premium Service Class Media Diff
Serv
CLI: media-qos
[PremiumServiceClassMediaDiffServ]
Global parameter that defines the DiffServ value for
Premium Media CoS content. You can also configure this
functionality per specific calls, using IP Profiles
(IpProfile_IPDiffServ). For a detailed description of this
parameter and for configuring this functionality in the IP
