User's Manual 5. Configuring Data-Router's LAN and WAN
Version 6.8 37 Mediant 500L MSBR
5 Configuring Data-Router's LAN and WAN
This section describes how to configure the device's data-router LAN and/or WAN
interfaces.
Notes:
• Make sure that you configure the LAN IP address of the data-router in the same
subnet as the VoIP-LAN IP address for OAMP.
• After you access the device through the default VoIP-LAN interface, you can
configure Web management access from one of the following interfaces:
√ Any of the configured data-router LAN interfaces: The default LAN data
interface is 192.168.0.1. This interface can be in a different subnet to the VoIP-
LAN IP address and with a different VLAN ID. This is useful, for example, if you
want to separate management from the VoIP traffic.
√ WAN port interface: In this setup, you need to enable remote access to the
WAN port interface, as described in ''Enabling Remote Management from
WAN'' on page 41.
5.1 Configuring Data-Router's LAN Interface
The device's default LAN IP address of the data-router is listed below:
IP Address: 192.168.0.1
Subnet Mask: 255.255.255.0
Default Gateway: 0.0.0.0
To configure LAN IP address of data-router:
1. Establish serial communication with the device.
2. At the prompt, type the following command to access the Data-router configuration
mode:
# configure data
3. Access the VLAN 1 LAN switch interface:
(config-data)# interface vlan 1
4. Configure the IP address and subnet:
(conf-if-VLAN 1)# ip address <IP address> <subnet>
For example:
(conf-if-VLAN 1)# ip address 10.8.6.85 255.255.255.0
5. Save your settings with a flash burn:
(conf-if-VLAN 1)# do write
