AudioCodes Mediant 500L MSBR User Manual

User's Manual 456 Document #: LTRT-10466
Mediant 500L MSBR
For supporting the E911 service, used the following configuration parameter settings:

Enable911PSAP = 1 (also forces the EnableDIDWink and EnableReversalPolarity)

HookFlashOption = 1 (generates the SIP INFO hookflash message) or 4 for RFC 2833
telephony event

WinkTime = 700 (defines detection window of 50 to 750 msec for detection of both
winks - 250 msec wink sent by the PSAP for starting the device's dialing; 500 msec
wink during the call)

IsTwoStageDial = 0

EnableHold = 0

EnableTransfer = 0
• Use RFC 2833 DTMF relay:
♦ RxDTMFOption = 3
♦ TxDTMFOption = 4
♦ RFC2833PayloadType = 101

TimeToSampleAnalogLineVoltage = 100

WaitForDialTime = 1000 (default is 1 sec)

SetDefaultLinePolarityState = 0 (you need to verify that the RJ-11 two-wire cable is
connected without crossing, Tip to Tip, Ring to Ring. Typically, the Tip line is positive
compared to the Ring line.)
Note: If the two-wire cable is crossed, the SetDefaultLinePolarityState parameter
must be set to 1.
The device expects to receive the ANI number in the From and/or P-Asserted-Identity SIP
header. If the pseudo-ANI number exists, it should be sent as the display name in these
headers.
Table 29-2: Dialed Number by Device Depending on Calling Number
Digits of Calling
Number (ANI)
Digits of Displayed Number Number Dialed MF Digits
8
"nnnnnnnn"
- MF dialed "KPnnnnnnnnST"
12
"nnnnnnnnnnnn"
None "KPnnnnnnnnnnnnSTP"
12
"nnnnnnnnnnnn"
10
"mmmmmmmmmm" (pANI)
"KPnnnnnnnnnnnnSTKPmmmmmmmmmmST"
2
"nn"
None "KPnnSTP"
1
"n"
- MF dialed "KPnST"
For example:
"From: <sip:8>@xyz.com>" generates device
MF spill of KP 8 ST
