Cisco ASA Series User Manual

1-6
Cisco ASA Series ASDM Configuration Guide
Chapter 1 Configuring the Switch for Use with the ASA Services Module
Using the MSFC as a Directly Connected Router
Information About SVIs
For security reasons, by default, you can configure one SVI between the MSFC and the ASASM; you
can enable multiple SVIs, but be sure you do not misconfigure your network.
For example, with multiple SVIs, you could accidentally allow traffic to pass around the ASASM by
assigning both the inside and outside VLANs to the MSFC. (See Figure 1-1.)
Figure 1-1 Multiple SVI Misconfiguration
ASA SM
MSFC
VLAN 200
VLAN 100
VLAN 201
V
LAN 201
Inside
249952
Internet
