1-21
Cisco ASA Series CLI Configuration Guide
Chapter 1 Configuring a Service Policy Using the Modular Policy Framework
Configuration Examples for Modular Policy Framework
hostname(config-pmap-c)# inspect http
hostname(config)# service-policy policy_serverB interface inside
hostname(config)# service-policy policy_serverA interface outside
Applying Inspection to HTTP Traffic with NAT
In this example, the Host on the inside network has two addresses: one is the real IP address 192.168.1.1,
and the other is a mapped IP address used on the outside network, 209.165.200.225. You must use the
real IP address in the access list in the class map. If you applied it to the outside interface, you would
also use the real address.
Figure 1-4 HTTP Inspection with NAT
See the following commands for this example:
hostname(config)# object network obj-192.168.1.1
hostname(config-network-object)# host 192.168.1.1
hostname(config-network-object)# nat (VM1,outside) static 209.165.200.225
hostname(config)# access-list http_client extended permit tcp host 192.168.1.1 any eq 80
hostname(config)# class-map http_client
hostname(config-cmap)# match access-list http_client
hostname(config)# policy-map http_client
hostname(config-pmap)# class http_client
hostname(config-pmap-c)# inspect http
hostname(config)# service-policy http_client interface inside
inside outside
Host
Real IP: 192.168.1.1
Mapped IP: 209.165.200.225
Server
209.165.201.1
port 80
insp.
Security
appliance
143416
