Item Value
Minimum Tx optical power (AVG)
[dBm]
-14 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 8.5 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1260 nm - 1360 nm
Rx sensitivity (AVG) [dBm] -32 dBm
Rx sensitivity (OMA) [dBm] -
Overload power (AVG) [dBm] -8 dBm
Overload power (OMA) [dBm] -
3.4.5 1Gbps Electrical Module
3.4.5.1 1Gbps-SFP-100m-industry (02310RAV)
Table 3-104 1Gbps-SFP-100m-industry specications
Item
Value
Basic Information
Module name 1Gbps-SFP-100m-industry
Part Number 02310RAV
Model OEGD01N01
Form factor SFP
Application standard IEEE 802.3, 1000Base-T
Connector type RJ45
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] -40°C to 85°C(-40°F to 185°F)
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 136
