Item Value
Rx sensitivity (OMA) [dBm] per lane: -8.6 dBm
Overload power (AVG) [dBm] per lane: 4.5 dBm
Overload power (OMA) [dBm] -
NOTE
The optical power calculation is based on the OMA value. The optical power read by the
device is the average optical power, not the OMA optical power.
3.4.19.8 100Gbps-QSFP28-1310nm-10km-commercial
Table 3-216 100Gbps-QSFP28-1310nm-10km-commercial
specications
Item Value
Basic Information
Module name 100Gbps-QSFP28-1310nm-10km-
commercial
Part Number 02314GYE
Model OSK002N01
Form factor QSFP28
Application standard IEEE 802.3cd, 100GBASE-LR1
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8636
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
CE Class B
ESD(HBM1) [V] 1000 V
Transmission rate [bit/s] 106.25 Gbit/s(PAM4)
Target transmission distance [km] 10 km
Transmitter Optical Characteristics
Center wavelength [nm] 1310 nm
Tx operating wavelength range [nm] 1304.5 nm - 1317.5 nm
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 284
