The ESD oor height is the distance between the upper surface of the ESD oor and the
surface of the concrete oor.
4.2.2.3 Cabinet Installation
The A610 series cabinets can be installed in
xed and or unxed mode. Both
methods apply to installation on concrete and ESD
oors.
4.2.2.3.1 Installing Cabinets on an ESD Floor
Perspective View After Installation
Figure 4-191 shows the perspective view of a single cabinet installed on an ESD
oor.
Figure 4-191 Single cabinet installed on an ESD oor
Figure 4-192 shows the perspective view of multiple cabinets installed on an ESD
oor.
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 531
