Item Value
Target transmission distance [km] 40 km
Transmitter Optical Characteristics
Center wavelength [nm] 1270 nm
Tx operating wavelength range [nm] 1260 nm - 1280 nm
Maximum Tx optical power (AVG)
[dBm]
5 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
0 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 3.5 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1320 nm - 1340 nm
Rx sensitivity (AVG) [dBm] -18 dBm
Rx sensitivity (OMA) [dBm] -
Overload power (AVG) [dBm] -9 dBm
Overload power (OMA) [dBm] -
3.4.13.2 10Gbps-SFP+-SMF-1330nm(Tx)/1270nm(Rx)-40km-commercial
Table 3-187 10Gbps-SFP+-SMF-1330nm(Tx)/1270nm(Rx)-40km-commercial
specications
Item
Value
Basic Information
Module name 10Gbps-SFP+-SMF-1330nm(Tx)/
1270nm(Rx)-40km-commercial
Part Number 02311JNQ
Model OSX040B11
Form factor SFP+
Application standard IEEE 802.3ae, 10GBASE-BX40-D
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 241
