3.4.12.8 10Gbps-SFP+-SMF-1611nm-70km-commercial
Table 3-185 10Gbps-SFP+-SMF-1611nm-70km-commercial specications
Item Value
Basic Information
Module name 10Gbps-SFP+-SMF-1611nm-70km-
commercial
Part Number 34060693
Model OSX070008
Form factor SFP+
Application standard IEEE 802.3ae, 10GBASE-X
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 9.953 Gbit/s
10.3125 Gbit/s
Target transmission distance [km] 70 km
Transmitter Optical Characteristics
Center wavelength [nm] 1611 nm
Tx operating wavelength range [nm] 1604.5 nm - 1617.4 nm
Maximum Tx optical power (AVG)
[dBm]
4 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
0 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 8.2 dB
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 239
