Item Value
Minimum extinction ratio [dB] 6 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1294.53 nm - 1296.59 nm
Rx sensitivity (AVG) [dBm] -15 dBm
Rx sensitivity (OMA) [dBm] -13.5 dBm
Overload power (AVG) [dBm] -3 dBm
Overload power (OMA) [dBm] -
NOTE
The optical power calculation is based on the OMA value. If the module needs to reach the
nominal data, the board FEC function must be enabled.
The optical power read by the device is the average optical power, not the OMA optical
power.
1. To keep the optical module running stably for a long time, set the receive optical power
less than -4 dBm. (According to IEEE 802.3, if the receive optical power exceeds -2.3 dBm,
the optical module may be permanently damaged.)
2. Before connecting the optical module, you are advised to use the optical power meter to
measure the receive optical power (P). If P is less than -4 dBm, the optical module can be
directly connected. If P is greater than -4 dBm, add an appropriate attenuator at the receive
end to ensure that P is less than -4 dBm. Alternatively, add an appropriate attenuator (the
recommended value is no less than 10 dB) before the optical module is connected, and
then adjust the attenuator according to the actual situation to prevent the module from
being damaged.
3. If the pigtail loopback or short-distance connection of the optical module is used, the
attenuator must be added. It is recommended that the attenuator be greater than or equal
to 10 dB.
4. When this type of optical module is used to interconnect with a WDM device, the 1+1
protection switching duration on the client side of the WDM device is longer than 50 ms.
3.4.19 100Gbps QSFP28 Optical Module
3.4.19.1 100Gbps(4*25.7)-QSFP28-MMF-850nm-0.1km-commercial
Table 3-209 100Gbps(4*25.7)-QSFP28-MMF-850nm-0.1km-commercial
specications
Item
Value
Basic Information
Module name 100Gbps(4*25.7)-QSFP28-
MMF-850nm-0.1km-commercial
Part Number 02311NTY
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 272
