Item Value
Tx operating wavelength range [nm] 1264.5 nm - 1277.5 nm
1284.5 nm - 1297.5 nm
1304.5 nm - 1317.5 nm
1324.5 nm - 1337.5 nm
Maximum Tx optical power (AVG)
[dBm]
per lane: 2.5 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
per lane: -6.5 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 3.5 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1264.5 nm - 1277.5 nm
1284.5 nm - 1297.5 nm
1304.5 nm - 1317.5 nm
1324.5 nm - 1337.5 nm
Rx sensitivity (AVG) [dBm] -
Rx sensitivity (OMA) [dBm] per lane: -10 dBm
Overload power (AVG) [dBm] per lane: 2.5 dBm
Overload power (OMA) [dBm] -
NOTE
1. If the module needs to reach the nominal data, the board FEC function must be enabled.
2. The BER 5x10E - 5 is the data that is not enabled by FEC, so that 1x10E - 12 can be
reached after FEC .
3.4.19.3 100Gbps(4*25.7)-QSFP28-SMF-1310nm-30km(NO FEC)-40km(FEC)-
commercial
Table 3-211 100Gbps(4*25.7)-QSFP28-SMF-1310nm-30km(NO FEC)-40km(FEC)-
commercial
specications
Item
Value
Basic Information
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 275
