Item Value
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
-9 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 9.5 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1270 nm - 1355 nm
Rx sensitivity (AVG) [dBm] -20 dBm
Rx sensitivity (OMA) [dBm] -
Overload power (AVG) [dBm] -3 dBm
Overload power (OMA) [dBm] -3 dBm
3.4.6.7 1.25Gbps-eSFP-SMF-1310nm-40km-commercial
Table 3-113 1.25Gbps-eSFP-SMF-1310nm-40km-commercial specications
Item
Value
Basic Information
Module name 1.25Gbps-eSFP-SMF-1310nm-40km-
commercial
Part Number S4016954
Model OSG040002
Form factor eSFP
Application standard IEEE 802.3, 1000BASE-EX
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 146
