Figure 4-309 Unqualied cable installation (seeing only the cable's outer
jacket from the viewing window)
4.2.12.2.3 Assembling Ethernet Cables
Assembling the Shielded RJ45 Connector and Ethernet Cable
Background
Figure 4-310 shows the components of an RJ45 connector and a shielded
Ethernet cable.
Figure 4-310 Shielded RJ45 connector and cable
A. Jacket of
connector
B. Metal shell of
connector
C. Wire holder of
connector
D. Plug of
connector
E. Jacket of
Ethernet cable
F. Shield layer of
Ethernet cable
G. Twisted-pair
wires
-
