Item Value
Center wavelength [nm] 1271nm,1291nm,1311nm,1331nm
Maximum Tx optical power (AVG)
[dBm]
2.3 dBm
Minimum Tx optical power (OMA)
[dBm]
-7.0 dBm
Minimum extinction ratio [dB] 3.5 dB
Receiver Optical Characteristics
Rx sensitivity (OMA) [dBm] -10.5 dBm
Overload power (AVG) [dBm] 3.5 dBm
NOTE
Application limitations:
- In actual applications, the number of conversion connectors for the optical ber link
cannot exceed 4.
- This module is sensitive to
ber link contamination. During deployment, ensure that the
ber endface meets the ber application standard. For details, see the single-mode
connector requirements under the ceramic ferrule endface requirements of bers in section
"Cable -Optical Jumper."
3.4.16.5 QSFP-40G-LX4-MM (02314MWG)
Table 3-201 QSFP-40G-LX4-MM
specications
Item
Value
Basic Information
Module name QSFP-40G-LX4-MM
Part Number 02314MWG
Model OMMD15N01
Form factor QSFP+
Application standard 40GBASE-LX4
Connector type LC
Optical ber type MMF
Working case temperature [°C(°F)] 0°C to 70°C (32°F to 158°F)
Transmission rate [bit/s] 40Gbit/s
Target transmission distance [km] 150m
Transmitter Optical Characteristics
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 260
