Figure 4-367 Installed MPO ber connector
4. To disassemble an MPO ber connector, hold the shell labeled "PULL" and
remove the male connector, as shown in Figure 4-368.
Figure 4-368 Disassembling an MPO ber connector
4.2.12.2.7 Replacing the Mold of the Crimping Tool
Procedure
1. Hold the handles of a pair of COAX crimping tools. Loosen the two fastening
screws counterclockwise, as shown in Figure 4-369.
Figure 4-369 Loosening two fastening screws
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 696
