Item Value
Minimum extinction ratio [dB] 3.5 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1320 nm - 1340 nm
Rx sensitivity (AVG) [dBm] -14.4 dBm
Rx sensitivity (OMA) [dBm] -10.3 dBm
Overload power (AVG) [dBm] 0.5 dBm
Overload power (OMA) [dBm] -
3.4.13.4 10Gbps-SFP+-SMF-1330nm(Tx)/1270nm(Rx)-10km-industry
Table 3-189 10Gbps-SFP+-SMF-1330nm(Tx)/1270nm(Rx)-10km-industry
specications
Item Value
Basic Information
Module name 10Gbps-SFP+-SMF-1330nm(Tx)/
1270nm(Rx)-10km-industry
Part Number 34060546-002
Model OSX010B11
Form factor SFP+
Application standard IEEE 802.3ae, 10GBASE-BX10-D
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] -40°C to 85°C(-40°F to 185°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 9.953 Gbit/s
10.3125 Gbit/s
Target transmission distance [km] 10 km
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 244
