Item Value
Center wavelength [nm] 1271 nm
1291 nm
1311 nm
1331 nm
Tx operating wavelength range [nm] 1264.5 nm - 1277.5 nm
1284.5 nm - 1297.5 nm
1304.5 nm - 1317.5 nm
1324.5 nm - 1337.5 nm
Maximum Tx optical power (AVG)
[dBm]
per lane: 2.3 dBm
Maximum Tx optical power (OMA)
[dBm]
per lane: 3.5 dBm
Minimum Tx optical power (AVG)
[dBm]
per lane: -7 dBm
Minimum Tx optical power (OMA)
[dBm]
per lane: -4 dBm
Minimum extinction ratio [dB] 3.5 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1264.5 nm - 1277.5 nm
1284.5 nm - 1297.5 nm
1304.5 nm - 1317.5 nm
1324.5 nm - 1337.5 nm
Rx sensitivity (AVG) [dBm] -
Rx sensitivity (OMA) [dBm] per lane: -11.5 dBm
Overload power (AVG) [dBm] per lane: 2.3 dBm
Overload power (OMA) [dBm] -
NOTE
The optical power calculation is based on the OMA value.
3.4.16.2 40Gbps(4*10.3)-QSFP+-MMF-850nm-0.1km-commercial
Table 3-198 40Gbps(4*10.3)-QSFP+-MMF-850nm-0.1km-commercial
specications
Item
Value
Basic Information
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 256
