Item Value
NOTE
1. If the module needs to reach the nominal data, the board FEC function must be enabled.
2. The BER 5x10E - 5 is the data that is not enabled by FEC, so that 1x10E - 12 can be
reached after FEC .
3. The optical power calculation is based on the OMA value. The optical power read by the
device is the average optical power, not the OMA optical power.
3.4.19.2 100Gbps(4*25.7)-QSFP28-SMF-1271~1331nm-2km-commercial
Table 3-210 100Gbps(4*25.7)-QSFP28-SMF-1271~1331nm-2km-commercial
specications
Item Value
Basic Information
Module name 100Gbps(4*25.7)-QSFP28-
SMF-1271~1331nm-2km-commercial
Part Number 02311QDH
Model OSN020N15
Form factor QSFP28
Application standard 100G CWDM4 MSA
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <5x10E-5
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8636
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 103.125 Gbit/s
Target transmission distance [km] 2 km
Transmitter Optical Characteristics
Center wavelength [nm] 1271 nm
1291 nm
1311 nm
1331 nm
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 274
