Item Value
NOTE
Only single-span applications are supported.
1. If the link loss is less than 22 dB (standard-dened), site survey is not required and an
OA only needs to be congured at the transmit end.
2. If the transmission distance ranges from 80 km to 120 km, site survey is required to
determine the OA
conguration scheme:
(1) If the link loss is less than or equal to 24 dB, an OA needs to be congured only at the
transmit end.
(2) If the link loss is greater than 24 dB but less than or equal to 28 dB, an OA needs to be
congured at both the transmit and receive ends, and the receive optical power threshold
of the involved module needs to be switched using a command.
(3) If the link loss is greater than 28 dB, optimize the link to ensure that the loss is less
than 28 dB.
(4) When this type of optical module is used to interconnect with WDM equipment, the
protection switching time of WDM client-side 1+1 protection is greater than 50 ms.
(5) According to the 400G ZR protocol, the hot start time of a 400G ZR optical module port
is less than 180s, and the cold start time of a 400G ZR optical module port is less than
200s.
3.4.20.7 400Gbps(4*100Gb/s PAM4)-QSFP-DD-SMF-1310nm-6km-commercial
Table 3-223 400Gbps(4*100Gb/s PAM4)-QSFP-DD-SMF-1310nm-6km-commercial
specications
Item
Value
Basic Information
Module name 400Gbps(4*100Gb/s PAM4)-QSFP-DD-
SMF-1310nm-6km-commercial
Part Number 02314LKG
Model OSK006NO1
Form factor QSFP-DD
Application standard IEEE802.3 bs-2017
Connector type LC
Optical ber type SMF
Bit error ratio (BER) 1E-6(Pre-FEC)
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options QSFP-DD MSA
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 297
