3.6.2 Breakout Boxes
3.6.2.1 Product Overview
Positioning
Breakout boxes are used to exibly allocate bandwidth resources to routers. They
cooperate with a breakout optical module and optical jumper to convert an MPO
interface into multiple LC interfaces to facilitate
ber layout.
Product Features
● LC interfaces support automatic dust-proof covers, and MPO interfaces
support dust-proof plugs.
● In comparison with breakout bers (MPO-LC bers), breakout boxes feature
more
exible ber layout.
● There is no restriction on the installation direction of breakout boxes, so that
the breakout boxes can be installed positively or negatively as needed.
Usage Scenario
The breakout function applies to a scenario where bandwidth resources are
unevenly allocated between two routers at dierent levels. In comparison with
breakout
bers, breakout boxes implement the following functions:
● Increase the density of ber layout.
● Shorten the cabling distance.
Figure 3-78 Breakout box cabling
3.6.2.2 10-Port-MPO-12-40-Port-LC-Breakout Box(single-mode)
Appearance
Figure 3-79 10-Port-MPO-12-40-Port-LC-Breakout Box(single-mode)
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 342
