Item Value
Minimum Tx optical power (AVG)
[dBm]
-2.8 dBm
Minimum Tx optical power (OMA)
[dBm]
0.2 dBm
Minimum extinction ratio [dB] 3.5 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1272.55 nm ~ 1274.54 nm
1276.89 nm ~ 1278.89 nm
1281.25 nm ~ 1283.27 nm
1285.65 nm ~ 1287.68 nm
1294.53 nm ~ 1296.59 nm
1299.02 nm ~ 1301.09 nm
1303.54 nm ~ 1305.63 nm
1308.09 nm ~ 1310.19 nm
Rx sensitivity (AVG) [dBm] -10.1 dBm
Rx sensitivity (OMA) [dBm] -7.1 dBm
Overload power (AVG) [dBm] 5.3 dBm
Overload power (OMA) [dBm] -
NOTE
When this type of optical module is used to interconnect with WDM equipment, the
protection switching time of WDM client-side 1+1 protection is greater than 50 ms.
3.4.20.2 400Gbps(8*56Gb/s PAM4)-QSFP-DD-SMF-1310nm-40km-commercial
Table 3-218 400Gbps(8*56Gb/s PAM4)-QSFP-DD-SMF-1310nm-40km-commercial
specications
Item
Value
Basic Information
Module name 400Gbps(8*56Gb/s PAM4)-QSFP-DD-
SMF-1310nm-40km-commercial
Part Number 02312YQG
Model OSK040N02
Form factor QSFP-DD
Application standard IEEE802.3 bs-2017
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 287
