Item Value
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1260 nm - 1360 nm
Rx sensitivity (AVG) [dBm] -
Rx sensitivity (OMA) [dBm] -23 dBm
Overload power (AVG) [dBm] -3 dBm
Overload power (OMA) [dBm] -
NOTE
Used in pair with 34060539.
3.4.7.5 1.25Gbps-eSFP-SMF-1570nm(Tx)/1490nm(Rx)-80km-commercial
Table 3-118 1.25Gbps-eSFP-SMF-1570nm(Tx)/1490nm(Rx)-80km-commercial
specications
Item
Value
Basic Information
Module name 1.25Gbps-eSFP-SMF-1570nm(Tx)/
1490nm(Rx)-80km-commercial
Part Number 34060595
Model OGEBIDI80
Form factor eSFP
Application standard IEEE 802.3ah, 1000Base-BX80-D
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 1.25 Gbit/s
Target transmission distance [km] 80 km
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 153
