Power Cable Routing Planning
It is recommended that power cables be routed on the left side of the cabinet.
It is recommended that cables, such as optical
bers, and Ethernet cables, be
routed on the left and right sides of the cabinet as the circumstances may require.
The following gures show the cable layout of the device.
Figure 4-263 Cable layout (from front side)
Figure 4-264 Cable layout (from back side)
4.2.7 Installation of cables
4.2.7.1 Installing Optical Fibers
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 611
