Item Value
Minimum Tx optical power (OMA)
[dBm]
per lane: 0.1 dBm
Minimum extinction ratio [dB] 8 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1294.53 nm - 1296.59 nm
1299.02 nm - 1301.09 nm
1303.54 nm - 1305.63 nm
1308.09 nm - 1310.19 nm
Rx sensitivity (AVG) [dBm] -
Rx sensitivity (OMA) [dBm] per lane: -21.4 dBm
Overload power (AVG) [dBm] per lane: -3.5 dBm
Overload power (OMA) [dBm] -
NOTE
1. If the module needs to reach 40km, the board FEC function must be enabled, otherwise
30km.
2. The BER 5x10E - 5 is the data that is not enabled by FEC, so that 1x10E - 12 can be
reached after FEC .
3. As a 30km application, the BER can reach 1x10E - 12
4. The optical power calculation is based on the OMA value. The optical power read by the
device is the average optical power, not the OMA optical power.
3.4.19.4 100Gbps(4*25.7)-QSFP28-SMF-1295.56~1309.14nm-10km-
commercial (02312BSS)
Table 3-212 100Gbps(4*25.7)-QSFP28-SMF-1295.56~1309.14nm-10km-
commercial
specications
Item
Value
Basic Information
Module name 100Gbps(4*25.7)-QSFP28-
SMF-1295.56~1309.14nm-10km-
commercial
Part Number 02312BSS
Model OSN010N24
Form factor QSFP28
Application standard IEEE 802.3ba, 100GBASE-LR4
Connector type LC
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 277
