Item Value

Center wavelength [nm] 1331 nm

Tx operating wavelength range [nm] 1324.5 nm - 1337.5 nm

Maximum Tx optical power (AVG)

[dBm]

4.2 dBm

Maximum Tx optical power (OMA)

[dBm]

4 dBm

Minimum Tx optical power (AVG)

[dBm]

-4.5 dBm

Minimum Tx optical power (OMA)

[dBm]

-1.5 dBm

Minimum extinction ratio [dB] 3.5 dB

Receiver Optical Characteristics

Rx operating wavelength range [nm] 1264.5 nm - 1277.5 nm

Rx sensitivity (AVG) [dBm] -

Rx sensitivity (OMA) [dBm] -8.9 dBm

Overload power (AVG) [dBm] 4.2 dBm

Overload power (OMA) [dBm] -

NOTE

1. The optical power calculation is based on the OMA value.

2. If the module needs to reach the nominal data, the board FEC function must be enabled.

3. When this type of optical module is used to interconnect with a WDM device, the 1+1

protection switching duration on the client side of the WDM device is longer than 50 ms.

3.4.18.2 50Gbps-QSFP28-SMF-1271nm(Tx)/1331nm(Rx)-10km-commercial

Table 3-206 50Gbps-QSFP28-SMF-1271nm(Tx)/1331nm(Rx)-10km-commercial

specications

Item

Value

Basic Information

Module name 50Gbps-QSFP28-SMF-1271nm(Tx)/

1331nm(Rx)-10km-commercial

Part Number 02312EVW

Model QSFP28-50G-BIDI-10km-SM-2

Form factor QSFP28

HUAWEI NetEngine 8000 F

Hardware Guide 3 Hardware Description
