Item Value
Maximum Tx optical power (OMA)
[dBm]
per lane: 4.5 dBm
Minimum Tx optical power (AVG)
[dBm]
per lane: -2.9 dBm
Minimum Tx optical power (OMA)
[dBm]
per lane: 0.1 dBm
Minimum extinction ratio [dB] 8 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1294.53 nm - 1296.59 nm
1299.02 nm - 1301.09 nm
1303.54 nm - 1305.63 nm
1308.09 nm - 1310.19 nm
Rx sensitivity (AVG) [dBm] per lane: -20.9 dBm
Rx sensitivity (OMA) [dBm] per lane: -21.4 dBm
Overload power (AVG) [dBm] per lane: -3.5 dBm
Overload power (OMA) [dBm] -
NOTE
When an optical module is installed on an interface, the FEC function on the interface is
disabled by default. Pay attention to the FEC status of the peer interface during
interconnection.
3.4.19.7 100Gbps(4*25.7)-QSFP28-SMF-1295.56~1309.14nm-10km-
commercial (02313SWA)
Table 3-215 100Gbps(4*25.7)-QSFP28-SMF-1295.56~1309.14nm-10km-
commercial
specications
Item
Value
Basic Information
Module name 100Gbps(4*25.7)-QSFP28-
SMF-1295.56~1309.14nm-10km-
commercial
Part Number 02313SWA
Model OSN010N24
Form factor QSFP28
Application standard IEEE 802.3ba, 100GBASE-LR4
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 282
