Item Value
Module name 1.25Gbps-eSFP-SMF-1550nm-80km-
commercial
Part Number 34060360
Model eSFP-1550nm-1000Base-Zx/FC100
Form factor eSFP
Application standard IEEE 802.3, 1000BASE-ZX
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1x10E-12
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options SFF-8472
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 500 V
Transmission rate [bit/s] 1.25 Gbit/s
Target transmission distance [km] 80 km
Transmitter Optical Characteristics
Center wavelength [nm] 1550 nm
Tx operating wavelength range [nm] 1500 nm - 1580 nm
Maximum Tx optical power (AVG)
[dBm]
5 dBm
Maximum Tx optical power (OMA)
[dBm]
-
Minimum Tx optical power (AVG)
[dBm]
-2 dBm
Minimum Tx optical power (OMA)
[dBm]
-
Minimum extinction ratio [dB] 9 dB
Receiver Optical Characteristics
Rx operating wavelength range [nm] 1260 nm - 1580 nm
Rx sensitivity (AVG) [dBm] -23 dBm
Rx sensitivity (OMA) [dBm] -
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 144
