Item Value
Form factor QSFP-DD
Application standard IEEE802.3 bs-2017
Connector type LC
Optical ber type SMF
Bit error ratio (BER) <1E-4(before FEC)
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options QSFP-DD MSA
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 1000 V
Transmission rate [bit/s] 425 Gbit/s
Target transmission distance [km] 2 km
Transmitter Optical Characteristics
Center wavelength [nm] 1271 nm
1291 nm
1311 nm
1331 nm
Tx operating wavelength range [nm] 1264.5 nm ~ 1277.5 nm
1284.5 nm ~ 1297.5 nm
1304.5 nm ~ 1317.5 nm
1324.5 nm ~ 1337.5 nm
Maximum Tx optical power (AVG)
[dBm]
per lane: 3.5 dBm
Maximum Tx optical power (OMA)
[dBm]
per lane: 3.7 dBm
Minimum Tx optical power (AVG)
[dBm]
per lane: -3.3 dBm
Minimum Tx optical power (OMA)
[dBm]
per lane: -0.3 dBm
Minimum extinction ratio [dB] 3.5 dB
Receiver Optical Characteristics
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 292
