Item Value
Connector type MPO-16
Optical ber type MMF
Bit error ratio (BER) <5E-6(Pre-FEC)
Working case temperature [°C(°F)] 0°C to 70°C(32°F to 158°F)
DDM options QSFP-DD MSA
Environment standard RoHS
Security standard FCC Class B, IEC 60825-1 Class 1
ESD(HBM1) [V] 1000 V
Transmission rate [bit/s] 425 Gbit/s
Target transmission distance [km] 100m@OM5
100m@OM4
70m@OM3
Transmitter Optical Characteristics
Center wavelength [nm] 850 nm
Tx operating wavelength range [nm] 840 nm~ 860 nm
Maximum Tx optical power (AVG)
[dBm]
per lane: 4 dBm
Maximum Tx optical power (OMA)
[dBm]
per lane: 3 dBm
Minimum Tx optical power (AVG)
[dBm]
per lane: -6.5 dBm
Minimum Tx optical power (OMA)
[dBm]
per lane: -4.5 dBm
Minimum extinction ratio [dB] 3 dB
Modulation mode PAM4
Receiver Optical Characteristics
Rx operating wavelength range [nm] 840 nm~ 860 nm
Minimum Rx optical power (AVG)
[dBm]
per lane: -8.4 dBm
Maximum Rx optical power (AVG)
[dBm]
per lane: 4 dBm
Maximum Rx optical power (OMA)
[dBm]
per lane: 3 dBm
HUAWEI NetEngine 8000 F
Hardware Guide 3 Hardware Description
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 294
