cabinet is not horizontal, adjust the adjusting anchor by using a socket
wrench.
Figure 4-31 Leveling the cabinet
Both the gap between cabinets and the vertical deviation should be no less than
3 mm.
2. Restoring the ESD oor.
Figure 4-32 Restoring the ESD oor
The ESD oor has been removed before you determine the installation position of the
supports. Cut the ESD oor according to the size of the cabinet.
For underoor cabling, place the cables before you restore the ESD oor.
Installing Cabinet Doors
1. Installing the cabinet doors.
Install the cabinet door after the inside components and cables. To install the
components inside the cabinets and cables, see the Installation Guide.
a. Align the door with the front face of the column.
b. Place the door on the lower lintel and close the door till the lower pin
automatically inserts into the hole in the lower lintel.
HUAWEI NetEngine 8000 F
Hardware Guide 4 Hardware Installation and Parts Replacement
Issue 05 (2023-03-31) Copyright © Huawei Technologies Co., Ltd. 372
