4. Connect the other end of the USB cable to the USB console port on the services
gateway (see Figure 24 on page 111).
5. Start your asynchronous terminal emulation application (such as Microsoft Windows
HyperTerminal), and select the new COM port installed by the USB Console driver
software. In most cases, this is the highest-numbered COM port in the selection menu.
6. Configure the port settings, as listed in Table 49 on page 112.
Table 49: Port Settings
ValuePort Settings
9600Bits per second
8Data bits
NoneParity
1Stop bits
NoneFlow control
7. If you have not already done so, power on the services gateway by pressing the Power
button on the front of the services gateway. Verify that the POWER LED on the front
panel turns green.
The terminal emulation screen on your management device displays the startup
sequence. When the services gateway has finished starting up, a login prompt appears.
8. Log in as the user root. No password is required at initial connection, but you must
assign a root password before committing any configuration settings.
Related
Documentation
Configuring the SRX550 High Memory Services Gateway Using J-Web on page 129•
• Connecting to the SRX550 High Memory Services Gateway from the CLI Remotely on
page 133
Connecting the CLI at the User End for the SRX550 High Memory Services Gateway
To connect to the CLI through a dial-up modem connected to the console port on the
SRX550 High Memory Services Gateway:
1. Connect a modem at your remote location to a management device.
2. Start your asynchronous terminal emulation application (such as Microsoft Windows
HyperTerminal) on the management device.
3. Select the COM port to which the modem is connected (for example, COM1).
4. Configure the port settings shown in Table 50 on page 113.
Copyright © 2016, Juniper Networks, Inc.112
SRX550 High Memory Services Gateway Hardware Guide
