FPC 0 FPC
PIC 0 6x GE, 4x GE SFP Base
PIC
Xcvr 6 REV 02 740-011613 PLN4Q4R SFP-SX
Xcvr 7 REV 02 740-011613 PLH5R83 SFP-SX
Xcvr 8 REV 02 740-011613 PPF68ZA SFP-SX
Xcvr 9 REV 02 740-011613 AM1301SZEZL SFP-SX
FPC 1 REV 00 750-064611 ACMX2090 FPC
PIC 0 1x T1E1 mPIM (RoHS)
FPC 2 REV 00 750-064613 ACMW2386 FPC
PIC 0 1x Serial mPIM (RoHS)
FPC 3 REV 00 750-064614 ACMZ1330 FPC
PIC 0 16x GE POE gPIM (RoHS)
FPC 6 REV 02 750-064615 ACMS8119 FPC
PIC 0 8x SFP gPIM (RoHS)
Xcvr 0 REV 01 740-013111 92244027 SFP-T
Xcvr 1 REV 02 740-011613 PLH5KLM SFP-SX
Xcvr 2 REV 02 740-011613 PPF68YU SFP-SX
Xcvr 3 REV 02 740-011613 PN356ST SFP-SX
Xcvr 4 REV 02 740-011613 PLN54T1 SFP-SX
Xcvr 5 REV 01 740-020465 DDK2008229 SFP-1000BASE-BX10-D
Xcvr 6 REV 02 740-011613 PPF68YV SFP-SX
Xcvr 7 REV 02 740-011613 PPF68YW SFP-SX
Power Supply 0 Rev 04 740-028131 WG02251 PS 645W DC
Power Supply 1 Rev 04 740-028131 WH02925 PS 645W DC
NOTE: In the show chassis hardware command, the Gigabit-Backplane
Physical Interface Module (GPIM) slot number is reported as an FPC number,
and the GPIM number (always 0) is reported as the PIC number.
Most components also have a serial number ID label attached to the
component body.
Related
Documentation
Contacting Customer Support on page 179•
• Return Procedure for the SRX550 High Memory Services Gateway on page 180
• Locating the SRX550 High Memory ServicesGatewayMini-PIM and GPIM Serial Number
Labels on page 181
• Listing the SRX550 High Memory Services Gateway Component Serial Numbers with
the CLI on page 181
• Information You Might Need to Supply to JTAC on page 182
Information You Might Need to Supply to JTAC
When requesting support from JTAC by telephone, be prepared to provide the following
information:
•
Your existing case number, if you have one
•
Details of the failure or problem
•
Type of activity being performed on the services gateway when the problem occurred
Copyright © 2016, Juniper Networks, Inc.182
SRX550 High Memory Services Gateway Hardware Guide
