Table 11: 8-Port Gigabit Ethernet SFP XPIM LED States
DescriptionStateColorLED
Port is online.OnGreenLINK
Port is offline.Off
Port is receiving or sending data.BlinkingGreenACT
Port might be online, but is not receiving or
sending data.
Off
The GPIM is functioning normally.OnGreenSTATUS
The GPIM is starting up, running diagnostics,
or going offline.
Yellow
The GPIM has failed.Red
The GPIM is not powered on, is offline, or is
not configured.
Off
8-Port Gigabit Ethernet SFP XPIM Supported Transceivers
You can customize the Ethernet interface type by using different 1-port small form-factor
pluggable (SFP) transceivers. Table 12 on page 27 lists the SFP transceivers and cables
supported on the 8-port Gigabit Ethernet SFP modules for XPIMs.
Table 12: 8-Port Gigabit Ethernet SFP XPIM Supported Modules
CableConnector Type (SFP Transceiver)Juniper Product Number
LC100BASE-FXSRX-SFP-FE-FX
EX-SFP-1FE-FX
LC1000BASE-LHSRX-SFP-1GE-LH
EX-SFP-1GE-LH
LC1000BASE-LXSRX-SFP-1GE-LX
EX-SFP-1GE-LX
LC1000BASE-SXSRX-SFP-1GE-SX
EX-SFP-1GE-SX
CAT-5e1000BASE-T, Copper TransceiverSRX-SFP-1GE-T
EX-SFP-1GE-T
LC1000BASE-BX10, at 10 km (TX 1310 nm / RX
1490 nm)
EX-SFP-GE10KT13R14
LC1000BASE-BX10, at 10 km (TX 1310 nm / RX
1550 nm)
EX-SFP-GE10KT13R15
27Copyright © 2016, Juniper Networks, Inc.
Chapter 3: Interface Module Description
