Clearance Requirements for Airflow and Hardware Maintenance of the SRX550 High
Memory Services Gateway
When planning the installation site for the SRX550 High Memory Services Gateway, you
need to allow sufficient clearance around the rack.
When planning the installation site for the services gateway, consider the following:
•
For the cooling system to function properly, the airflow around the chassis must be
unrestricted. Figure 15 on page 58 shows the direction of airflow through the chassis.
Figure 15: Airflow Through the Chassis
Copyright © 2016, Juniper Networks, Inc.58
SRX550 High Memory Services Gateway Hardware Guide
