CHAPTER 2
Chassis Description
•
SRX550 High Memory Services Gateway Chassis on page 13
•
SRX550 High Memory Services Gateway Front Panel on page 14
•
SRX550 High Memory Services Gateway Front Panel LEDs on page 17
•
SRX550 High Memory Services Gateway Back Panel on page 19
SRX550 High Memory Services Gateway Chassis
The SRX550 High Memory Services Gateway chassis is a rigid sheet metal structure that
houses all the other hardware components.
Table 5 on page 13 provides information about the physical specifications for the services
gateway.
Table 5: Physical Specifications for the SRX550 High Memory Services
Gateway
ValuePhysical Specification
3.5 in. (8.8 cm)Chassis height
17.5 in. (44.4 cm)Chassis width
18.2 in. (46.2 cm)Chassis depth
21.96 lb. (9.96 kg)Chassis weight (includes one power supply without any
GPIMs or Mini-PIMs)
CAUTION: Beforeremovingor installing componentsof a functioning services
gateway, attach an electrostatic discharge (ESD) strap to an ESD point and
place the other end of the strap around your bare wrist. Failure to use an ESD
strap could result in damage to the device.
The services gateway must be connected to earth ground during normal operation. The
protective earthing terminal on the side of the chassis is provided to connect the services
13Copyright © 2016, Juniper Networks, Inc.
