Juniper SRX550 Hardware Guide

•
Maximum module power of 40 W without PoE
•
JTAG support for boundary scan test
16-Port Gigabit Ethernet XPIM (PoE) Components
The 16-Port Gigabit Ethernet XPIM contains the components listed in Table 14 on page 30.
Table 14: 16-Port Gigabit Ethernet XPIM Components
DescriptionLocationComponent
Use the XPIM
ONLINE/OFFLINE button to
gracefully shut down the XPIM.
Right side of the XPIMXPIM ONLINE/OFFLINEbutton
The SRX550 High Memory
Services Gateway does not
support hot-swappable
functionality for GPIMs.
Each port on the 16-Port
Gigabit Ethernet with PoE
XPIM supports Power over
Ethernet (PoE).
Middle of the XPIM16 PoE ports labeled 0 to 15
Use the captive screws to hold
the XPIM in place in the
services gateway.
One on each side of the XPIMCaptive screws
Use the handles to grasp the
XPIM for installation or
removal.
One on each side of the XPIMHandles
16-Port Gigabit Ethernet XPIM (PoE) Hardware Specifications
Table 15 on page 30 provides the specifications for the 16-Port Gigabit Ethernet XPIM.
Table 15: 16-Port Gigabit Ethernet XPIM Hardware Specifications
ValueDescription
1.58 in. x 6.72 in. x 8.5 in.
(4.0 cm x 17.1 cm x 21.6 cm)
Dimensions (H x W x L)
16.5 oz (0.68 kg)Weight
16 RJ-45Connector type
Double-high, single-wide XPIMForm factor
32° F through 104° F (0° C through 40° C)Environmental operating temperature
-40° F through 158° F (-40° C through 70° C)Storage temperature
5% to 90% noncondensingRelative humidity
Copyright © 2016, Juniper Networks, Inc.30
SRX550 High Memory Services Gateway Hardware Guide
