Juniper SRX550 Hardware Guide

•
RS-232
•
RS-449
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) Hardware Specifications
Table 17 on page 33 lists the physical specifications of the 1-Port Serial Mini-Physical
Interface Module (Mini-PIM).
Table 17: 1-Port Serial Mini-PIM (SRX-MP-1SERIAL-R) Physical
Specifications
ValueDescription
0.8 in. x 3.75 in. x 5.9 in.
(2.0 cm x 9.5 cm x 14.5 cm)
Dimensions (H x W x L)
3.04 oz (86 g)Weight
60-pin Synchronous Serial (female)Connector type
Mini-PIMForm factor
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) LEDs
The 1-Port Serial Mini-Physical Interface Module (Mini-PIM) has one LED located to the
right of the serial port. Table 18 on page 33 describes the LED states.
Table 18: 1-Port Serial Mini-PIM (SRX-MP-1SERIAL-R) LED States
DescriptionStateColorName
Online with no alarms or failures.OnGreenSTATUS
Device has detected a failure.Off
1-Port Serial Mini-Physical Interface Module Interface Cables
Table 19 on page 33 lists the cables that you can order from Juniper Networks to connect
to a port on the synchronous 1-Port Serial Mini-Physical Interface Module (Mini-PIM).
The device to which you are connecting and the serial interface types determine which
type of cable you need.
Table 19: Juniper Networks Serial Cables
Connector
TypeLengthInterface TypeProduct Number
Female3.04 m (10 ft)EIA530 cable (DCE)JX-CBL-EIA530-DCE
Male3.04 m (10 ft)EIA530 cable (DTE)JX-CBL-EIA530-DTE
33Copyright © 2016, Juniper Networks, Inc.
Chapter 3: Interface Module Description
