1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R) Network Interface Specifications
The 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) has the network interface
specifications given in Table 22 on page 37.
Table 22: 1-Port T1/E1 Mini-PIM (SRX-MP-1T1E1-R) Network Interface
Specifications
E1 SpecificationsT1 SpecificationSpecification
Network interface specifications
2.048 Mbps1.544 MbpsTransmit bit rate
2.048 Mbps1.544 MbpsReceive bit rate
HDB3AMI/B8ZSLine encoding
Framed Clear Channel,
Unframed Clear Channel
Framed Clear ChannelMode
G704 without CRC4 UnframedSuperframe (D4/SF), Extended
Superframe (ESF)
Fractional Framing
HDLC features
(E1:N=1 to 31)(T1:N=1 to 24)N x 64 Kbps or N x 56 Kbps,
nonchannelized data rates
16/3216/32CRC
SupportedSupportedShared Flag
SupportedSupportedIdle flag/fill
Runts, Giants, FCS, Error, Abort
Error, Align Error
Runts, Giants, FCS, Error, Abort
Error, Align Error
Counters:
Related
Documentation
• SRX550 High Memory ServicesGateway Gigabit-Backplane PhysicalInterface Modules
Overview on page 23
• 8-Port Gigabit Ethernet SFP XPIM on page 25
• 16-Port Gigabit Ethernet XPIM (PoE) on page 29
• SRX550 High Memory Services Gateway Mini-Physical Interface Modules Overview
on page 31
• 1-Port Serial Mini-Physical (SRX-MP-1SERIAL-R) Interface Module on page 32
37Copyright © 2016, Juniper Networks, Inc.
