CHAPTER 8
Cabinet Requirements
•
SRX550 High Memory Services Gateway Cabinet Size and Clearance
Requirements on page 61
•
SRX550 High Memory Services Gateway Cabinet Airflow Requirements on page 62
SRX550 High Memory Services Gateway Cabinet Size and Clearance Requirements
You can install the SRX550 High Memory Services Gateway in a 19 in. (48.3 cm) cabinet
as defined in Cabinets, Racks, Panels, and Associated Equipment (document number
EIA-310-D) published by the Electronic Industries Alliance
(http://www.ecaus.org/eia/site/index.html). You must mount the services gateway
horizontally in the cabinet.
NOTE: The holes in the mounting brackets chassis are spaced 1.25 in (3.2
cm) apart, measured from the center of the hole.
When selecting a cabinet, ensure that the physical characteristics of the cabinet comply
with the following specifications:
•
The cabinet is at least 2U (3.50 in. or 8.89 cm) and can accommodate the services
gateway.
•
The outer edges of the mounting brackets extend the width of either chassis to 19 in.
(48.2 cm), and the front of the chassis extends approximately 0.5 in (1.27 cm) beyond
the mounting brackets.
•
The minimum total clearance inside the cabinet is 30.7 in. (78 cm) between the inside
of the front door and the inside of the rear door.
NOTE: A cabinet larger than the minimum required provides better airflow
and reduces the chance of overheating.
Related
Documentation
SRX550 High Memory Services Gateway Chassis on page 13•
• SRX550 High Memory Services Gateway Cabinet Airflow Requirements on page 62
61Copyright © 2016, Juniper Networks, Inc.
