23 TECHNICAL DATA 193
Cylinder head screw M10 Tightening sequence:
Tighten diagonally, begin-
ning with the rear screw on
the timing chain shaft.
Step 1
15 Nm (11.1 lbf ft)
Step 2
30 Nm (22.1 lbf ft)
Step 3
45 Nm (33.2 lbf ft)
Step 4
60 Nm (44.3 lbf ft)
Lubricated with engine oil
Oil line for oil pressure sensor M10x1 10 Nm (7.4 lbf ft) –
Oil pressure sensor M10x1 10 Nm (7.4 lbf ft) –
Plug, drain hole of water pump M10x1 15 Nm (11.1 lbf ft) –
Screw plug, oil channel M10x1 15 Nm (11.1 lbf ft) Loctite
®
243™
Screw plug, oil channel, for oil radiator M10x1 15 Nm (11.1 lbf ft) –
Screw, unlocking of timing chain ten-
sioner
M10x1 10 Nm (7.4 lbf ft) –
Spark plug outside M10x1 11 Nm (8.1 lbf ft) –
Spark plug inside M12x1.25 18 Nm (13.3 lbf ft) –
Coolant temperature sensor on cylinder
head
M12x1.5 12 Nm (8.9 lbf ft) –
Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft) –
Oil pressure regulator valve plug M12x1.5 20 Nm (14.8 lbf ft) –
Screw plug, oil channel M14x1.5 15 Nm (11.1 lbf ft) Loctite
®
243™
Engine case stud M16x1.5 25 Nm (18.4 lbf ft) Loctite
®
243™
Rotor nut M18x1.5 100 Nm (73.8 lbf ft) –
Nut, engine sprocket M20x1.5 80 Nm (59 lbf ft) Loctite
®
243™
Nut, inner clutch hub M20x1.5 100 Nm (73.8 lbf ft) Loctite
®
243™
Nut, primary gear M20LHx1.5 90 Nm (66.4 lbf ft) Loctite
®
243™
Plug, oil screen M20x1.5 15 Nm (11.1 lbf ft) –
Plug, timing chain tensioner M20x1.5 25 Nm (18.4 lbf ft) –
Plug, oil thermostat M24x1.5 15 Nm (11.1 lbf ft) –
Screw in alternator cover M24x1.5 8 Nm (5.9 lbf ft) –
23.4 Capacities
23.4.1 Engine oil
Engine oil 1.70 l (1.8 qt.) Engine oil (SAE 10W/60) (00062010035) ( p. 224)
Alternative engine oil Engine oil (SAE 10W/50)
( p. 224)
23.4.2 Coolant
Coolant 1.20 l (1.27 qt.) Coolant ( p. 224)
Coolant (mixed ready to use) ( p. 224)
23.4.3 Fuel
Total fuel tank capacity,
approx.
12 l (3.2 US gal) Super unleaded (ROZ 95/RON 95/PON 91) ( p. 225)
Fuel reserve, approx. 2.5 l (2.6 qt.)
