8 SHOCK ABSORBER, SWINGARM 37

G00742-13

– Lift the rear fairing.

–

Remove screws



G00818-11

–

Remove screws



G00825-11

–

Loosen screw



–

Remove screw



–

Remove screw



G00824-10

– Fold the rear upward.

–

Take out shock absorber



toward the top.

8.10 Installing the shock absorber

G00824-11

Main work

–

Fold the rear upward and maneuver in shock absorber



from above.

– Fold the rear down and position the shock absorber.
