23 TECHNICAL DATA 194
23.5 Chassis
Frame Lattice frame made of chrome molybdenum steel tubing,
powder-coated
Fork WP Suspension 4860 ROTA SPLIT
Shock absorber WP Suspension 4618 with Pro‑Lever deflector
Suspension travel
Front 215 mm (8.46 in)
Rear 250 mm (9.84 in)
Brake system
Front Disc brake with radially screwed four-piston brake caliper, float-
ing brake disc
Rear Disc brake with single-piston brake caliper, floating
Brake discs - diameter
Front 320 mm (12.6 in)
Rear 240 mm (9.45 in)
Brake discs - wear limit
Front 4.0 mm (0.157 in)
Rear 4.5 mm (0.177 in)
Tire air pressure, solo
Front 2.0 bar (29 psi)
Rear 2.0 bar (29 psi)
Tire air pressure with passenger / fully loaded
Front 2.0 bar (29 psi)
Rear 2.2 bar (32 psi)
Secondary drive ratio 16:42
Chain 5/8 x 1/4” X‑ring
Steering head angle 63°
Wheelbase 1,480±15 mm (58.27±0.59 in)
Seat height unloaded 890 mm (35.04 in)
Ground clearance unloaded 270 mm (10.63 in)
Weight without fuel, approx. 144 kg (317 lb.)
Maximum permissible front axle load 150 kg (331 lb.)
Maximum permissible rear axle load 200 kg (441 lb.)
Maximum permissible overall weight 350 kg (772 lb.)
23.6 Electrical system
Battery YTZ10S Battery voltage: 12 V
Nominal capacity: 8.6 Ah
maintenance-free
Fuse 58011109130 30 A
Fuse 58011109125 25 A
Fuse 75011088015 15 A
Fuse 75011088010 10 A
Headlight H4 / socket P43t 12 V
60/55 W
Parking light W5W / socket W2.1x9.5d 12 V
5 W
Instrument lights and indicator lamps LED
Turn signal RY10W / socket BAU15s 12 V
10 W
Brake/tail light LED
License plate lamp W5W / socket W2.1x9.5d 12 V
5 W
