Parameter Name / value range / [default seng] Info
0x282A:002
(P126.02)
Status words: Cause of quick stop
(Status words: Cause of QSP)
•
Read only
Bit coded display of the cause(s) of quick stop.
Bit 0 Flexible I/O conguraon 1 ≡ quick stop was acvated by the trigger set in 0x2631:003 (P400.03).
Bit 1 Network 1 ≡ quick stop was acvated via network.
Bit 2 Axis command 1 ≡ quick stop was acvated via axis command .
Bit 6 Error response 1 ≡ quick stop has been acvated as a response to an error.
0x282A:003
(P126.03)
Status words: Cause of stop
(Status words: Cause of stop)
•
Read only
Bit coded display of the cause(s) of stop.
Bit 0 Flexible I/O: Start disabled 1 ≡ stop was acvated by the trigger set in 0x2631:002 (P400.02).
Bit 1 Flexible I/O: Run forward 1 ≡ stop has been acvated due to cancellaon of the command "Run
forward (CW)".
Bit 2 Flexible I/O: Run reverse 1 ≡ stop has been acvated due to cancellaon of the command "Run
reverse (CCW)".
Bit 3 Flexible I/O: Jog forward 1 ≡ stop has been acvated due to cancellaon of the command "Jog
foward (CW)".
Bit 4 Flexible I/O: Jog reverse 1 ≡ stop has been acvated due to cancellaon of the command "Jog
reverse (CCW)".
Bit 5 Network 1 ≡ stop was acvated via network.
Bit 6 Keypad 1 ≡ stop was acvated via keypad.
Bit 7 Control mode transion 1 ≡ stop has been acvated due to a change of the operang mode.
Bit 8 End of sequence 1 ≡ stop was acvated by the "sequencer" funcon since the sequence is
completed.
•
The bit is only set aer the sequence is completed if End of sequence
mode0x402F (P824.00) is set ="Stop [1]" or "Stop and abort [2]".
Bit 15 Waing for start 1 ≡ Stop is acve as a start command is not yet available (e.g. aer ena-
bling the inverter).
0x282A:004 Status words: Extended status word
•
Read only
Bit-coded status word.
Bit 8 Reverse rotaonal direcon 1 ≡ reversal acve.
Bit 10 Safe torque o (STO) acve 1 ≡ "Safe torque o (STO)" funcon has been triggered by the integrated
safety system.
Bit 11 Both STO channels not acve 1 ≡ safe inputs SIA and SIB = LOW (simultaneously).
0x282A:005
(P126.05)
Status words: Device status
(Status words: Device status)
•
Read only
Display of the current inverter device state.
0 Inialisaon
2 Not ready to switch on
3 Switch on disabled
4 Ready to switch on
5 Switched on
6 Operaon enabled
7 Disable operaon
8 Shut down
9 Quick stop acve
10 Fault reacon acve
11 Fault
0x282B:001
(P125.01)
Inverter diagnoscs: Acve control source
(Inverter diag.: Acve control)
•
Read only
Display of the control source that is currently acve.
0 Flexible I/O conguraon
1 Network
2 Keypad
8 Keypad full control
Diagnoscs and fault eliminaon
Diagnoscs parameter
Inverter diagnoscs
115
