Parameter Name / value range / [default seng] Info
0x400C:004
(P593.04)
Process output data: Motor speed
(Process data OUT: Motor speed)
•
Read only: x rpm
Mappable parameter for the output of the actual value as speed in [rpm]
via network.
•
The output is eected without sign (irrespecve of the rotang direc-
on).
•
The rotang direcon is specied via the status word.
•
Example: 456 ≡ 456 rpm
0x400C:005
(P593.05)
Process output data: Drive status
(Process data OUT: Drive status)
•
Read only
Mappable status word (Modbus Legacy Register 2003).
0 Error (non-reseable) acve
1 Error acve
2 Waing for start
3 Idencaon not executed
4 Inverter disabled
5 Stop acve
7 Idencaon acve
8 Running
9 Acceleraon acve
10 Deceleraon acve
11 Deceleraon override acve
12 DC braking acve
13 Flying start acve
14 Current limit reached
16 Process controller idle state
0x400C:006
(P593.06)
Process output data: Frequency (0.01)
(Process data OUT: Frequency 0.01)
•
Read only: x.xx Hz
Mappable parameter for the output of the actual frequency value in
[0.01 Hz] via network.
•
The output is eected without sign (irrespecve of the rotang direc-
on).
•
The rotang direcon is specied via the status word.
•
Example: 456 ≡ 4.56 Hz
0x400C:007
(P593.07)
Process output data: Torque scaled
(Process data OUT: Torque scaled)
•
Read only
•
From version 02.00
Mappable parameter for the output of the actual torque value in [Nm /
2
scaling factor
] via network.
•
The scaling factor can be set in 0x400B:009 (P592.09).
•
Actual torque value = scaled actual torque value (0x400C:007) / 2
scaling
factor
Example:
•
Scaled actual torque value (0x400C:007) = 345 [Nm]
•
Scaling factor (0x400B:009) = 3
•
Actual torque value = 345 [Nm] / 2
3
= 43.125 [Nm]
0x400C:008
(P593.08)
Process output data: Frequency [0.02 Hz]
(Process data OUT: Frequency 0.02Hz)
•
Read only: Hz
•
From version 04.00
Mappable parameter for the output of the actual frequency value in
[0.02 Hz] via network.
•
The output is eected without sign (irrespecve of the rotang direc-
on).
•
The rotang direcon is specied via the status word.
•
Examples: 50 ≡ 1 Hz, 100 ≡ 2 Hz
0x400C:009
(P593.09)
Process output data: Frequency [+/-16384]
(Process data OUT: Freq. [+/-16384])
•
Read only
•
From version 05.00
Mappable parameter for the output of the actual frequency value via
network.
•
±16384 ≡ ±100 % Maximum frequency 0x2916 (P211.00)
Conguring the network
Predened process data words
Further process data
256
