Parameter Name / value range / [default seng] Info
0x400A:002
(P591.02)
Process output words: NetWordOUT2
(NetWordOUTx: NetWordOUT2)
•
Read only
Mappable data word for the output of messages of the "Sequencer"
funcon via network.
Conguraon of the messages:
•
0x4026:008: NetWordOUT2 value for sequencer segment 1
•
0x4027:008: NetWordOUT2 value for sequencer segment 2
•
0x4028:008: NetWordOUT2 value for sequencer segment 3
•
0x4029:008: NetWordOUT2 value for sequencer segment 4
•
0x402A:008: NetWordOUT2 value for sequencer segment 5
•
0x402B:008: NetWordOUT2 value for sequencer segment 6
•
0x402C:008: NetWordOUT2 value for sequencer segment 7
•
0x402D:008: NetWordOUT2 value for sequencer segment 8
•
0x402E:008: NetWordOUT2 value for nal segment
Bit 0 Mapping bit 0
Bit 1 Mapping bit 1
Bit 2 Mapping bit 2
Bit 3 Mapping bit 3
Bit 4 Mapping bit 4
Bit 5 Mapping bit 5
Bit 6 Mapping bit 6
Bit 7 Mapping bit 7
Bit 8 Mapping bit 8
Bit 9 Mapping bit 9
Bit 10 Mapping bit 10
Bit 11 Mapping bit 11
Bit 12 Mapping bit 12
Bit 13 Mapping bit 13
Bit 14 Mapping bit 14
Bit 15 Mapping bit 15
0x400B:003
(P592.03)
Process input data: Network setpoint frequency (0.1)
(Process data IN: Net.freq. 0.1)
0.0 ... [0.0] ... 599.0 Hz
Mappable parameter for specifying the frequency setpoint in [0.1 Hz] via
network.
•
The specicaon is made without sign (irrespecve of the rotang
direcon).
•
The rotang direcon is specied via the control word.
•
Example: 456 ≡ 45.6 Hz
0x400B:004
(P592.04)
Process input data: Network setpoint speed
(Process data IN: Net.setp. speed)
0 ... [0] ... 50000 rpm
Mappable parameter for specifying the setpoint as speed in [rpm] via
network.
•
The specicaon is made without sign (irrespecve of the rotang
direcon).
•
The rotang direcon is specied via the control word.
•
Example: 456 ≡ 456 rpm
0x400B:005
(P592.05)
Process input data: Network setpoint frequency (0.01)
(Process data IN: Net.freq. 0.01)
0.00 ... [0.00] ... 599.00 Hz
Mappable parameter for specifying the frequency setpoint in [0.01 Hz]
via network.
•
The specicaon is made without sign (irrespecve of the rotang
direcon).
•
The rotang direcon is specied via the control word.
•
Example: 456 ≡ 4.56 Hz
0x400B:009
(P592.09)
Process input data: Torque scaling
(Process data IN: Torque scaling)
-128 ... [0] ... 127
•
From version 02.00
Scaling factor for torque setpoint 0x400B:008 (P592.08) and actual tor-
que value 0x400C:007 (P593.07) via network.
•
With the seng 0, no scaling takes place.
0x400B:012
(P592.12)
Process input data: Network setpoint frequency
[0.02Hz]
(Process data IN: NetSereq0.02Hz)
-29950 ... [0] ... 29950 Hz
•
From version 04.00
Mappable parameter for specifying the frequency setpoint in [0.02 Hz]
via network.
•
The specicaon is made without sign (irrespecve of the rotang
direcon).
•
The rotang direcon is specied via the control word.
•
Examples: 50 ≡ 1 Hz, 100 ≡ 2 Hz
0x400B:013
(P592.13)
Process input data: Network frequency setpoint
[+/-16384]
(Process data IN: N.FrqSet+/-16384)
-32768 ... [0] ... 32767
•
From version 05.00
Mappable parameter for specifying the frequency setpoint via network.
•
±16384 ≡ ±100 % Maximum frequency 0x2916 (P211.00)
0x400C:003
(P593.03)
Process output data: Frequency (0.1)
(Process data OUT: Frequency (0.1))
•
Read only: x.x Hz
Mappable parameter for the output of the actual frequency value in
[0.1 Hz] via network.
•
The output is eected without sign (irrespecve of the rotang direc-
on).
•
The rotang direcon is specied via the status word.
•
Example: 456 ≡ 45.6 Hz
Conguring the network
Predened process data words
Further process data
255
