Parameter Name / value range / [default seng] Info
0x23A1:001
(P510.01)
EtherNet/IP sengs: IP address
(EtherN/IP se.: IP address)
0 ... [276605120] ... 4294967295
•
From version 02.00
Set IP address.
The default seng 276605120 corresponds to the IP address
192.168.124.16.
•
276605120 = 0x107CA8C0 à 0xC0.0xA8.0x7C.0x10 = 192.168.124.16
0x23A1:002
(P510.02)
EtherNet/IP sengs: Subnet
(EtherN/IP se.: Subnet)
0 ... [16777215] ... 4294967295
•
From version 02.00
Set subnet mask.
The default seng 16777215 corresponds to the subnet mask
255.255.255.0.
•
16777215 = 0xFFFFFF à 0xFF.0xFF.0xFF.0x00 = 255.255.255.0
0x23A1:003
(P510.03)
EtherNet/IP sengs: Gateway
(EtherN/IP se.: Gateway)
0 ... [0] ... 4294967295
•
From version 02.00
Set gateway address.
Example:
The seng 276344004 corresponds to the gateway address
196.172.120.16.
•
276344004 = 0x1078ACC4 à 0xC4.0xAC.0x78.0x10 = 196.172.120.16
0x23A1:004
(P510.04)
EtherNet/IP sengs: Host name
(EtherN/IP se.: Host name)
•
From version 02.00
Set host name.
•
String with up to 64 characters.
0x23A1:005
(P510.05)
EtherNet/IP sengs: IP conguraon
(EtherN/IP se.: IP conguraon)
•
From version 02.00
Set IP conguraon.
0 Stored IP The currently saved IP conguraon is used.
1 BOOTP The IP conguraon is assigned by the Scanner via BOOTP.
2 DHCP The IP conguraon is assigned by the Scanner via DHCP.
The assignment of a gateway address that is not in the same subnetwork
as the IP address, is denied.
0x23A1:006
(P510.06)
EtherNet/IP sengs: Mulcast TTL
(EtherN/IP se.: Mulcast TTL)
1 ... [1] ... 255
•
From version 02.00
Seng of the mulcast TTL value for the validity of data packages in the
network.
0x23A1:007
(P510.07)
EtherNet/IP sengs: Mulcast allocaon
(EtherN/IP se.: Mcast allocaon)
•
From version 02.00
Selecon for mulcast-IP addressing.
0 Default allocaon
1 Mulcast number/start address
0x23A1:008
(P510.08)
EtherNet/IP sengs: Mulcast IP address
(EtherN/IP se.: Mcast IP addr.)
0 ... [3221373167] ... 4294967295
•
From version 02.00
Set mulcast IP address.
The default seng 3221373167 corresponds to the Mulcast IP address
239.64.2.192.
•
3221373167 = 0xC00240EF à 0xEF.0x40.0x02.0xC0 = 239.64.2.192
0x23A1:009
(P510.09)
EtherNet/IP sengs: Mulcast number
(EtherN/IP se.: Mulcast number)
1 ... [1] ... 8
•
From version 02.00
Set mulcast number.
0x23A4:001
(P512.01)
Port sengs: Port 1
(Port sengs: Port 1)
•
From version 02.00
Set baud rate for Ethernet port 1.
0 Auto-Negoaon
1 10 Mbps
2 100 Mbps
3 Reserved
4 Reserved
5 10 Mbps/Half Duplex
6 10 Mbps/Full Duplex
7 100 Mbps/Half Duplex
8 100 Mbps/Full Duplex
9 Reserved
10 Reserved
11 Reserved
12 Reserved
Conguring the network
EtherNet/IP
Basic sengs
319
