Rigging work
12.5 Operating the outriggers
Operating manual 3 302 819 en 12 - 41
GMK3060
13.12.2018
From the
crane cab
The following operating elements are found in the Outriggermenu.
Starting the engine
• Start the engine from the crane cab; à p. 10 - 3.
• Switch off the slewing gear.
Opening the menu
• Open the Outrigger menu (1).
• Select and confirm the symbol (2) – Move
outrigger cylinders.
Extend
• Press the button for the desired outrigger
cylinder.
• Also press the button (5) in at the top – the
selected supporting cylinder extends.
s
1 Front left
2 Front right
3 Rear left
4 Rear right
