Omron MX2 Series User Manual

4 Parameter List
4 - 3
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Monitor or data range
Default
data
Changes
during
RUN
Unit
Page
d010
Torque Bias Monitor
−200 to 200
−
−
−
%
d012
Output Torque Moni-
tor
−200 to 200
−
−
%
P. 7-8
d013
Output Voltage Moni-
tor
0.0 to 600.0
−
−
V
P. 7-8
d014
Input Power Monitor
0.0 to 100.0
−
−
kW
P. 7-9
d015
Integrated Power
Monitor
0.0 to 1000000.0
*1
−
−
−
P. 7-9
d016
Total RUN Time Mon-
itor
0. to 1000000.
*1
−
−
h
P. 7-10
d017
Total Power ON Time
Monitor
0. to 1000000.
*1
−
−
h
P. 7-10
d018
Fin Temperature
Monitor
−20.0 to 150.0
−
−
°C
P. 7-10
d022
Life Assessment
Monitor
2 1
1: Capacitor on main circuit board
2: Cooling fan
−
−
−
P. 7-11
d023
Program Counter
(DriveProgramming)
1 to 1024
−
−
−
P. 7-11
d024
Program Number
Monitor
(DriveProgramming)
0 to 9999
−
−
−
P. 7-11
d025
User Monitor 0
(DriveProgramming)
Displays DriveProgramming execution
result.
−2147483648 to 2147483647
*1
(Displays upper 5 digits excluding “-”)
−
−
−
P. 7-12
d026
User Monitor 1
(DriveProgramming)
d027
User Monitor 2
(DriveProgramming)
d029
Position Command
Monitor
−268435455 to 268435455
(1 multiplication)
*1
(Displays upper 5 digits excluding “-”)
−
−
pulse
P. 7-12
d030
Current Position
Monitor
−268435455 to 268435455
(1 multiplication)
*1
(Displays upper 5 digits excluding “-”)
−
−
pulse
P. 7-12
d050
Dual User Monitor (2
types of data)
Displays data set in b160 and b161.
−
−
−
P. 7-13
d060
Inverter Mode Moni-
tor
Displays the currently set mode.
I-C (IM motor heavy load)
I-V (IM motor light load)
H-I (IM motor high frequency)
P (PM motor mode)
−
−
−
P. 7-13
*1. The digit shift display mode can be used.
4
4-1 Monitor Mode
4-1-1 Group d
